Fresh Air Processing Indoor Unit

GMV-N AHU + Fresh Air Processing Indoor Unit + Control System Lineup serisi Fresh Air Processing Indoor Unit tipi ürün — 95.536 BTU / 28.0 kW kapasiteli. Fresh air processing indoor unit. Rated cooling 28.0kW. Sayfa 077/078: GREE CAC GMV-N serisi hava isleme ic unite teknik spec tablolari. Ust tablo GMV-N AHU modeller kombinasyonlarini, alt tablo Fresh Air Processing Indoor Unit modellerini kapsar. Sag: kontrolor uyumluluk matrisi. Teknik Özellikler: - Capacity cooling kw rated: 28.0 - Capacity heating kw rated: 18.0 - Capacity heating kw max: 22.0 - Power supply: 220-240V~50Hz & 208-230V~60Hz - Power consumption w cooling: 520 - Power consumption w heating: 860 - Airflow total m3h default adjustable: 2500/1000~300 - Airflow fresh m3h default adjustable: 400/1000~300 - Rated current a cooling: 2.5/4.3 - Rated current a heating: 3.1/4.9 - Sound pressure level dba default range: 47/41~64 - Connecting pipe liquid mm: Ø9.52 - Connecting pipe gas mm: Ø22.2 - Drain pipe mm: Ø25 - Drain pipe thickness mm: 2.0 - Dimension outline mm: 1463x791x385 - Dimension package mm: 1578x883x472 - Net weight kg: 82/104 - Loading quantity 20gp: 52 - Soğutma Kapasitesi (kW): 28.0 - Isıtma Kapasitesi (kW): 18.0 Model Kodu: GMV-NDX280P/A-T
