Floor Ceiling Type Fan Coil Unit 51 2-pipe

Fan Coil Unit - Floor Ceiling Type serisi Fan Coil Unit - Floor Ceiling (2-pipe) tipi ürün — 9.384 BTU / 2.75 kW kapasiteli. Floor ceiling tipi fan coil, 2-boru sistemi GREE CAC Floor Ceiling Type Fan Coil Unit. Ozellikler: Optimized air duct design to improve fan efficiency and lower operation noise. Fan will not work if water inlet temp is lower than setting value to avoid warm air under cooling condition. Test kosullari 2-pipe: Sogutma DB=27C WB=19C Water Inlet=7C Outlet=12C; Isitma DB=20C WB<=15C Water Inlet=45C Outlet=40C. Test kosullari 4-pipe: Sogutma DB=27C WB=19C Water Inlet=7C Outlet=12C; Isitma DB=20C WB<=15C Water Inlet=65C Outlet=55C. Teknik Özellikler: - Pipe system: 2-pipe - Air flow m3h h m l: 510/400/300 - Air flow cfm h m l: 300/235/176 - Capacity cooling kw: 2.75 - Capacity heating kw: 3.4 - Power supply: 220-240V~50Hz - Input kw: 0.073 - Cooling water flow ls: 0.13 - Cooling water flow gpm: 2.1 - Heating water flow ls: 0.18 - Heating water flow gpm: 2.5 - Cooling pressure drop kpa: 30 - Cooling pressure drop ftwg: 9.8 - Heating pressure drop kpa: 30 - Heating pressure drop ftwg: 9.8 - Noise dba: 46 - Dimension outline wxdxh mm: 592x592x240 - Dimension package mm: 675x670x85 - Weight net gross kg: 20/24 - Connection pipe water inlet outlet inner thread inch: Rc3/4 - Connection pipe condensed water drain outer thread mm: 31 - Panel outline mm: 670x85x670 - Panel package mm: 760x760x90 - Panel weight net gross kg: 3.5/5 - Loading 40gp 40hq: 258/291 - Standard wireless remote: YB1FA(MOTO) - Optional wireless remote: XE70-17/E(M) - Soğutma Kapasitesi (kW): 2.75 - Isıtma Kapasitesi (kW): 3.4 Model Kodu: FP-51XD/A-K
